Introducing the all-new MEZZBARRIERS OPEN TOP LOW HEADROOM/HIGH LOAD ‘HI-GATE’ MULTI-PURPOSE SAFETY PALLET GATE

***WATCH A VIDEO TO SEE IT IN ACTION***

After extensive development and testing, the Mezzbarriers team are pleased to announce this exciting new concept in safety pallet gate design.

Based on our proven standard Hi-Gate multi-purpose open-top model, we have significantly reduced the headroom required for this innovative dual-gate system while retaining its unique fool-proof operation.

The New Hi-Gate Advantages Over Ordinary Up-and-Over Pallet Gates are:

● The open top accepts unlimited load height and allows loading by either forklift or overhead hoist.

● Lower headroom – Can operate below standard room height at 2.35 metres for 1.5 metres inside gate width, and the open
top gives significantly more clearance for tall pallets, especially where headroom is reduced.

● It does not protrude over the floor edge, whether open or shut, reducing the chance of collision with a rising load.

● Minimal working depth – The opening gate scissors up to one side (Left or right-handed operation to suit location) – It takes up less operational floor depth.

● An anti-slam damper within the bi-directional gates linking mechanism prevents gates from inadvertently plummeting, preventing operator injury.

● Option for an asymmetric edge gate which reduces the gap width required. The fixed top half projects out beyond the loor edge to allow clearance of the adjacent handrail – It also allows the edge gate to be positioned nearer to the floor edge for optimum forklift loading.

● Option for custom inside width up to 2.0 metres, ideal for bulkier pallets or wider load baskets.

● Option for increased inside depth (Up to 4 metres) for handling longer loads by hoist. Loads can remain suspended through the loading sequence and continue beyond the inner gate if required.

● Longer working life – Mechanical construction allows replacing damaged or worn parts.

● Full compliance with ISO 14122-3:2016 testing and safety requirements - It protects all personnel from moving loads and falling from unprotected edges during loading operations and at all other times.

Click here to find out more and request your no-obligation quotation.

Want to see it in action? Arrange a demonstration at our Manchester works – Call 0161 223 1990 today.
