Pfaff Silberblau HU ES 10 B Manual push - Electric High lift pallet truck 1,000 kg

In stock
Quantity

Key Features

  • A combination of hand pallet truck and elevating platform for the transport and raising of palletised loads to various work areas
  • Ergonomic control button for the hydraulic unit fitted in the handle.
  • In the case of battery failure the manual use of lifting and lowering is stiil guaranteed.
  • Quick electric-hydraulic lifting of the load, pressure relief valve protects against overloading.
  • Low noise and smooth running due to polyurethane steering and load rollers as standard.
Delivery Options

Scissor pallet truck with Electric-hydraulic lift

Capacity: 1000kg
A combination of hand pallet truck and elevating platform for the transport and raising of palletised loads to various departments. Manual and electric options are available.

HU ES 10B (Electric/hydraulic lift) features:

•   Increases the usefulness of the HU HS 10 B manual hydraulic by saving operating time for demanding applications with frequent lifting and lowering operations.
•   Ergonomic control button for the hydraulic unit fitted in the handle.
•   In the case of battery failure the manual use of lifting and lowering is stil guaranteed.
•   Quick electric-hydraulic lifting of the load, pressure relief valve protects against overloading.
•   Low noise and smooth running due to polyurethane steering and load rollers as standard.
•   Additional tilting protection for the load rollers.
•   Comes complete with battery and battery charger.


ModelHU ES 10 B
Article no.26900020
Lift capacityQkg1000
Load centrecmm600
Weightkg167
Tyre type**PUR/PUR
Steering rollersmm180 x 50
Load rollersmm75 x 50
No. of wheels/load rollers2 / 2
Strokeh3mm715
Max. height of handleh14mm1230
Fork height loweredh13mm85
Overall lengthl1mm1740
Overall widthb1/b2mm540
Fork heightsmm50
Fork widthemm160
Fork lengthlmm1170
Outside fork dimensionb5mm540
Ground clearancem2mm35
Aisle width palletAstmm1990
Turning circle radiusWamm1450
Battery chargerV/A220 / 8
Battery voltage, capacityk5V/Ah12 / 52
**PUR...Polyurethane.
