Tiger chain block type CB 500 kg to 5,000 kg - Manual Chain Hoists - Hoists - Lifting, Hoisting and Winching

In stock
Only %1 left
SKU
250387

Tiger chain block type CB 500 kg to 5,000 kg

From £145.91 £121.59
In stock
Quantity

Key Features

  • Buy online in popular heights of lift 3m,4m,5m,6m and 9m (For other lifts please contact us)
  • Rugged steel body construction
  • High quality alloy calibrated load chain
  • Meets or exceeds all international standards
  • Safe reliable twin pawl mechanical brake
Delivery Options

Delivery Information

Order online for delivery to Mainland UK VAT eligible locations only. Delivery charges will be shown in the shopping cart. Despatch dates for products can vary, if urgent, please contact us. Request a quote for postcodes DD, IV, KW, PA, AB, BT, HS, TR. PO30-PO42, southern Ireland, Channel Islands. For international destinations restrictions may apply.

Returns Policy

Simply email us at sales@dale-lifting.co.uk or call 0161 223 1990 and we will be able to give you a returns authorisation code, which must be sent with the returned item. Returns should be authorised within 14 days from the day of delivery to you. Items should be returned in unused condition & due to the nature of our products a restocking fee may apply. Unfortunately, delivery charges are not refundable. Items returned without an authorisation code may not be accepted. Normally All refunds will be processed within 7- 10 working days on receipt of returned goods.

Non-standard (Quote only, pre-order or custom-made products)

Custom made to order products are not covered by our returns policy. Please ensure when ordering all measurements and capacities are correct as we are unable to refund on these products.

For more information see https://www.dlhonline.co.uk/terms-conditions

Tiger TCB Hand Chain Block
Buy online in popular heights of lift 3m,4m,5m,6m and 9m
For other heights of lift required please contact us

Main Features

  • Rugged steel body construction
  • Drop forged & heat treated alloy hooks
  • Certified 2% light load protection
  • Proof tested to 1.5 times rated capacity
  • Suitable for underground mining use
  • Lightweight and portable
  • High quality alloy calibrated load chain
  • Heat treated alloy steel triple spur gears and pinion shaft
  • Can be chained to meet your exact requirements
  • Tested and certified for “fleeting” and “cross-hauling” applications up to 45°
  • Meets or exceeds all international standard
  • Double cover protection for brake chamber
  • Safe reliable twin pawl mechanical brake
  • Operating temperature of -40°C to +50°C
  • Individual spares readily available
  • Overload protection available
Model select Product Code Capacity (Tonne) Effort (Kg) Load Chain Load Chain Height of Lift (standard) (m) Mass @ STD HOL (Kg)
        Diameter (mm) No. of Falls
500/1 CB-0050 0.5 21 6.3 1 3 10.8
1000/1 CB-0100 1.0 25 6.3 1 3 11.8
1500/1 CB-0150 1.5 32 7.1 1 3 16.2
2000/1 CB-0200 2.0 34 8.0 1 3 20.0
2000L/1 CB-020L 2.0 42 7.1 1 3 16.7
3000/1 CB-0300 3.0 38 10.0 1 3 30.6
3000T/1 CB-030T 3.0 34 7.1 2 3 23.3
5000/3 CB-0500 5.0 37 8.0 3 3 37.8
Shown separately CB-0800 8.0 37 8.0 4 3 64.0
CB-1000 10.0 40 10.0 3 3 64.0
CB-1500 15.0 41 10.0 5 3 128.5
CB-2000 20.0 43 10.0 6 3 178.7
CB-200T 20.0 43 10.0 6 3 210.4
CB-3000 30.0 42 10.0 10 3 306.9


Options

  • Available with stainless steel load chain (Contact us)
  • Available with forged clevis adaptor components (Contact us

Certification:

Each unit comes fully certified with a test certificate or an EC Declaration of Conformity stating compliance with the essential health and safety requirements of the Machinery Directive 2006/42/EC. This document clearly states the proof test at 1.5 times the rated capacity and the light load test of 2% of the rated capacity, which exceeds the requirements of the current applicable standard.
