Yale YELB 'Single-acting Hydraulic Cylinders with safety lock nut'
Delivery Information
Order online for delivery to Mainland UK VAT eligible locations only. Delivery charges will be shown in the shopping cart. Despatch dates for products can vary, if urgent, please contact us. Request a quote for postcodes DD, IV, KW, PA, AB, BT, HS, TR. PO30-PO42, southern Ireland, Channel Islands. For international destinations restrictions may apply.
Returns Policy
Simply email us at sales@dale-lifting.co.uk or call 0161 223 1990 and we will be able to give you a returns authorisation code, which must be sent with the returned item. Returns should be authorised within 14 days from the day of delivery to you. Items should be returned in unused condition & due to the nature of our products a restocking fee may apply. Unfortunately, delivery charges are not refundable. Items returned without an authorisation code may not be accepted. Normally All refunds will be processed within 7- 10 working days on receipt of returned goods.
Non-standard (Quote only, pre-order or custom-made products)
Custom made to order products are not covered by our returns policy. Please ensure when ordering all measurements and capacities are correct as we are unable to refund on these products.
For more information see https://www.dlhonline.co.uk/terms-conditions
To receive a quotation please advise model No.
Hydraulic cylinders with safety lock nuts are recommended when loads have to remain in the raised position over a period of time. The safety lock nut ensures a positive lead hold in any position and work can be carried out beneath the lifted load. Hydraulic pressure can be released so that cylinders work like mechanical supports. Pumps can be separated from cylinders.
Features
- Operating pressure max. 700 bar.
- Single-acting with gravity return.
- Generous guiding bands ensure a robust piston guiding.
- Hard chromium-plated piston with trapezoid thread.
- Overflow hole ensures a definite piston end stop.
- Interchangeable hardened saddle.
- Oil port thread: 3/8 NPT.
- Includes female coupler half, model CFY-1.
- All YEL cylinders/jacks have lifting rings.
Technical Specifications
| Model |
Cylinder Size (tonne) |
Oil Vol. Max. (cm3) |
Stroke (mm) |
Closed Height (mm) |
| YELB 30/50 | 30 | 221 | 50 | 169 |
| YELB 30/100 | 30 | 442 | 100 | 219 |
| YELB 30/150 | 30 | 663 | 150 | 265 |
| YELB 50/50 | 50 | 355 | 50 | 185 |
| YELB 50/100 | 50 | 710 | 100 | 235 |
| YELB 50/150 | 50 | 1063 | 150 | 285 |
| YELB 93/50 | 93 | 663 | 50 | 200 |
| YELB 93/100 | 93 | 1327 | 100 | 250 |
| YELB 93/150 | 93 | 1989 | 150 | 300 |
| YELB 140/50 | 140 | 1005 | 50 | 210 |
| YELB 140/100 | 140 | 2010 | 100 | 260 |
| YELB 140/150 | 140 | 3015 | 150 | 310 |
| YELB 220/150 | 220 | 4710 | 150 | 345 |
